ESP32-CAM WiFi Bluetooth Camera Development Board

LKR 2,300.00 Original price was: LKR 2,300.00.LKR 2,160.00Current price is: LKR 2,160.00.
In Stock

This product has been added to 8 people'scarts.

Order on WhatsApp
In Stock
Add to wishlist
  • Delivered today (order Mon-Fri before 12:00, delivery between 17:00 and 22:00)
  • Including shipping costs, sent by blonwe.com
  • Pick up at a blonwe.com collection point is possible
  • 30 days to change your mind and free returns
  • Day and night customer service
SKU: RB045
Categories: , ,

Description

In the world of microcontrollers, the ESP32-CAM stands out as a versatile and compact development board that integrates both Wi-Fi/Bluetooth capabilities and a camera module. Developed by Espressif Systems, the ESP32-CAM is designed for projects that require image and video processing, making it a popular choice among hobbyists, makers, and IoT enthusiasts. In this review, we’ll delve into the key features, performance, and potential use cases of the ESP32-CAM, shedding light on why it has become a go-to solution for camera-enabled projects.

Features

The smallest 802.11b/g/n Wi-Fi BT SoC module.
Low power 32-bit CPU, can also serve the application processor.
Up to 160MHz clock speed, summary computing power up to 600 DMIPS.
Built-in 520 KB SRAM, external 4MPSRAM.
Supports UART/SPI/I2C/PWM/ADC/DAC.
Support OV2640 and OV7670 cameras, built-in flash lamp.
Support image WiFI upload.
Supports TF card.
Supports multiple sleep modes.
Embedded Lwip and FreeRTOS.
Supports STA/AP/STA+AP operation mode.
Support Smart Config/AirKiss technology.
Support for serial port local and remote firmware upgrades (FOTA).
Specifications

Wireless Module: ESP32-S WiFi 802.11 b/g/n + Bluetooth 4.2 LE module with PCB antenna, u.FL connector, 32Mbit SPI flash, 4MBit PSRAM.
External Storage: micro SD card slot up to 4GB.
Camera
FPC connector.
Support for OV2640 (sold with a board) or OV7670 cameras.
Image Format: JPEG( OV2640 support only ), BMP, grayscale.
LED flashlight.
Expansion: 16x through-holes with UART, SPI, I2C, PWM.
Misc: Reset button.
Power Supply: 5V via pin header.
Power Consumption.
Flash LED off: 180mA @ 5V.
Flash LED on to maximum brightness: 310mA @ 5V.
Deep-sleep: 6mA @ 5V min.
Modem-sleep: 20mA @ 5V min.
Light-sleep: 6.7mA @ 5V min.
Dimensions (ESP32): 40 x 27 x 12 (L x W x H) mm.
Temperature Range: Operating: -20 ℃ ~ 85 ℃; storage: -40 ℃ ~ 90 ℃ @ < 90>
