Description

The TXS0108E 8-channel (8-bit) bi-directional level-shifter (logic level converter) works with both open-drain and push-pull configurations. This 8-bit translator uses two separate configurable power-supply rails. The A port tracks the VA (VCCA) pin supply voltage. The VA pin accepts any supply voltage between 1.2 V and 3.6 V. The B port tracks the VB (VCCB) pin supply voltage. The VB pin accepts any supply voltage between 1.65 V and 5.5 V.
When the output-enable (OE) input pin is low, all outputs are placed in the high-impedance (Hi-Z) state.

  • Voltage level: 1.8V-6V
  • Dimension: 21mm x 15mm
  • 8 channels bidirectional voltage translation between different logic levels, translate between Ax and Bx automatically
  • How to Use
  • GND connects to power negative pole respectively, the two power supplies should be common-grounded with each other
  • When Ax has TTL 3.3V input, Bx will get TTL 5V output
  • When Bx has TTL 5V input, Ax will get TTL 3.3V output
  • In the case of translating between 3.3V and 5V systems:
  • VCCA connects to a 3.3V power supply
  • VCCB connects to a 5V power supply
